Premium Vibration Isolation & Pressure Management
The S-Flex Tied Pump Flexible is engineered to control vibration, reduce noise, and manage thermal expansion in heating and chilled water systems. With its reinforced EPDM rubber construction and anti-tamper carbon steel tie bars, this flexible connection ensures a secure installation while preventing elongation under pressure.
Designed for demanding commercial and industrial applications, the S-Flex Tied Pump Flexible delivers a full-bore flow, eliminating pressure drop concerns while providing enhanced durability and longevity. It is the ideal solution for maintaining the efficiency and lifespan of pumps and pipework.
Key Features
-
Vibration & Noise Control – Effectively absorbs movement in heating and chilled water systems.
-
Anti-Tamper Tie Bars – Ensures optimal installation length and prevents overextension.
-
Steel Reinforced Collars – Provides added strength and durability.
-
Nylon-Reinforced EPDM Rubber – Offers flexibility and long-lasting resistance to wear and tear.
-
Full Bore Flow Design – Eliminates pressure drops for maximum system efficiency.
-
Flanged Carbon Steel Connections – PN16 drilled, compliant with BS EN1092 standards.
-
Extended Design Life – Built for long-term performance, with a 10-year design life and 12-month warranty.
Applications
-
HVAC & Mechanical Systems – Reduces vibration in heating and cooling systems.
-
Pump Installations – Protects pumps from excessive movement and stress.
-
Industrial & Commercial Use – Enhances the efficiency and durability of mechanical systems.
Technical Specifications
| Size (mm) |
Installed Length (mm) |
Material Type |
Temperature Limits (°C) |
Part Code |
| 32 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/032/PN16T |
| 40 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/040/PN16T |
| 50 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/050/PN16T |
| 65 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/065/PN16T |
| 80 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/080/PN16T |
| 100 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/100/PN16T |
| 125 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/125/PN16T |
| 150 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/150/PN16T |
| 200 |
130 |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/200/PN16T |
| 250 |
On Request |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/250/PN16T |
| 300+ |
On Request |
Nylon Reinforced EPDM |
-10 to 90 |
SUP/300/PN16T |
Important Notes
- Not suitable for potable water, oil-based fluids, compressed air, or food applications.
- Should not be installed on pumps mounted on inertia bases.
- Must be installed without applying torsional forces to the unit.
- DIN 4809 Approved Pump Flexibles available upon request.
Enhance System Performance with S-Flex
With superior vibration isolation, secure tie-bar construction, and long-lasting durability, the S-Flex Tied Pump Flexible is the ideal choice for ensuring efficiency and reliability in industrial and commercial HVAC systems.
|
|
S-Flex Tied Pump Flexible – High-performance nylon-reinforced EPDM rubber connector with integral tie bars to control movement, reduce vibration, and prevent overextension in heating and chilled water systems. Designed for secure and efficient operation.
